Stay connected with Wi-Fi 6
Highlights
- Stable mesh networking, up to 4,000 sq. ft. Wi-Fi coverage
- Dual-Band Wi-Fi 6 for a smooth online experience
- Swift wireless speed up to 2,976Mbps
- Reliable connection for up to 254 devices
Specs
| Hardware configuration | Processor Qualcomm® IPQ5000 Dual-core A53 1.0GHz CPU Network processing unit Single core 1.0GHz NPU Memory 256MB 2.4G Wi-Fi 2×2 (supports up to IEEE 802.11ax protocol, the theoretical maximum rate is 574Mbps) 5GHz Wi-Fi 2×2 (supports up to IEEE 802.11ax protocol, the theoretical maximum rate is 2402Mbps) Antennas High gain antennas Heat dissipation Natural heat dissipation Total ports 1×10/100/1000Mbps self-adaptive WAN port (Auto MDI/MDIX) 3×10/100/1000Mbps self-adaptive LAN ports (Auto MDI/MDIX) LED indicator light 2 lights, System indicator × 1, Internet indicator × 1 System reset button×1 Mesh networking button×1 Power input port×1 Protocol standards IEEE 802.11a/b/g/n/ac/ax，IEEE 802.3/3u/3ab |
| Wireless specifications | Dual-band 2.4GHz, 5GHz Modulation 11b：DSSS：DBPSK(1Mbps),DQPSK(2Mbps),CCK(5.5/11Mbps) 11a/g: OFDM:BPSK(6/9Mbps),QPSK(12/18Mbps),16QAM(24/36Mbps), 64QAM(48/54Mbps) 11n：MIMO-OFDM:BPSK,QPSK,16QAM,64QAM. Data rate：MCS0-MCS15 11ac：MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM. 11ax：MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM,1024QAM. Data rates: MCS0-MCS11 (supports 2 streams). |
| Software specifications | Operating system MiWiFi ROM, a smart router operating system based on OpenWRT WiFi Encryption WPA-PSK/WPA2-PSK/WPA3-SAE encryption, Wireless access control (black and white list), SSID hidden Management applications Supports Web, Android, iOS |
| Working Environment | Working environment Temperature 0-40℃ Operating humidity 10%-90%RH (non-condensing) Storage temperature -40-70℃ Storage humidity 5%-90%RH (non-condensing) |
