Ready When You Are
With every detail, DJI RS 3 delivers a flexible and efficient shooting experience to solo creators and independent crews. Light and sleek, it provides professional stabilization and efficient control for more creative freedom and endless possibilities. DJI RS 3 is ready when you are.
Highlights
- Quick-release plates
- Automated-axis locks
- Wireless Shutter Control
Specs
| Peripheral | Accessory Port NATO Ports 1/4″-20 Mounting Hole Cold Shoe Video Transmission/Focus Motor Port (USB-C) RSS Camera Control Port (USB-C) Focus Motor Port (USB-C) Battery Model: BHX711-3000-7.2V Type: 2S Capacity: 3000 mAh Energy: 21 Wh Max. Runtime: 12 hours [1] Charging Time: Approx. 2.5 hours when using 18W quick charging (supports PD protocol) Suggested Charging Temperature: 5° to 40° C (41° to 104° F) Connections Bluetooth 5.0 Charging Port (USB-C) Ronin App Requirements iOS 11.0 or above Android 7.0 or above Languages Supported by the Touchscreen English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai |
| Working Performance | Tested Payload 3 kg (6.6 lbs) Maximum Controlled Rotation Speed Pan: 360°/s Tilt: 360°/s Roll: 360°/s Mechanical Range Pan axis: 360° continuous rotation Roll axis: -95° to +240° Tilt axis: -112° to +214° |
| Mechanical & Electrical Properties | Operating Frequency 2.400-2.484 GHz Bluetooth Transmitter Power <8 dBm Operating Temperature -20° to 45° C (-4° to 113° F) Weight Gimbal: Approx. 990 g (2.18 lbs) Grip: Approx. 200 g (0.44 lbs) Extended Grip/Tripod (Plastic): Approx. 183 g (0.4 lbs) Upper and Lower Quick-Release Plates: Approx. 107 g (0.23 lbs) Dimensions Folded: 254×230×68 mm (L×W×H, excluding camera, grip, and the Extended Grip/Tripod) Unfolded: 364×187×170 mm (L×W×H, height includes the grip and excludes the Extended Grip/Tripod) |
| DJI Ronin Image Transmitter | Connections Power/Communication Port (USB-C) HDMI Port (Mini HDMI) RSS Camera Control Port (USB-C) Expansion Port Cold Shoe Operating Frequency 2.400-2.484 GHz 5.725-5.850 GHz Weight 126 g (0.27 lbs) Dimensions 82×63×24 mm (L×W×H) Transmitter Power (EIRP) 2.400-2.484 GHz: <25 dBm (FCC) <20 dBm (CE/SRRC/MIC) 5.725-5.850 GHz: <25 dBm (FCC/SRRC) <14 dBm (CE) Battery Capacity: 2970 mAh Compatible Charger: 5V/2A Charging Time: Approx. 2.5 hours Max Battery Life: Approx. 3.5 hours Transmission Range 200 m (SRRC/FCC) [2] 100 m (CE) [2] Latency 60 ms Operating Current/Voltage 900 mA, 3.7V Operating Temperature 0° to 45° C (32° to 113° F) |
