Fly Mini, Create Big
Highlights
- Under 249 g
- Tri-Directional Obstacle Sensing
- 4K HDR Video
- Extended Battery Life
- True Vertical Shooting
- FocusTrack
Specs
| Aircraft | Takeoff Weight <249 g [1] Dimensions (L×W×H) Folded: 145×90×62 mm Unfolded: 171×245×62 mm Unfolded (with propellers): 251×362×70 mm Diagonal Length 247 mm Max Ascent Speed 5 m/s (S Mode) 3 m/s (N Mode) 2 m/s (C Mode) Max Descent Speed 5 m/s (S Mode) 3 m/s (N Mode) 1.5 m/s (C Mode) Max Speed (at sea level, no wind) [2] 16 m/s (S Mode) 10 m/s (N Mode) 6 m/s (C Mode) Max Service Ceiling Above Sea Level With Intelligent Flight Battery: 4000 m With Intelligent Flight Battery Plus [7]: 3000 m [3] Max Flight Time 34 mins (with Intelligent Flight Battery and measured while flying at 21.6 kph in windless conditions) 47 mins (with Intelligent Flight Battery Plus [7] and measured while flying at 21.6 kph in windless conditions). Only available in select countries. Max Hovering Time 30 mins (with Intelligent Flight Battery, no wind) 40 mins (with Intelligent Flight Battery Plus [7], no wind) Max Flight Distance 18 km (with Intelligent Flight Battery and measured while flying at 43.2 kph in windless conditions) 25 km (with Intelligent Flight Battery Plus [7] and measured while flying at 43.2 kph in windless conditions) Max Wind Speed Resistance 10.7 m/s (Level 5) Max Pitch Angle Forward: 40°, Backward: 35° (S Mode) 25° (N Mode) 25° (C Mode) Max Angular Velocity (by default)* 130°/s (S Mode) * Can be adjusted between 20°/s and 250°/s in the app 75°/s (N Mode) * Can be adjusted between 20°/s and 120°/s in the app 30°/s (C Mode) * Can be adjusted between 20°/s and 60°/s in the app Operating Temperature -10° to 40° C (14° to 104° F) Global Navigation Satellite System (GNSS) GPS + Galileo + BeiDou Operation Frequency 2.400-2.4835 GHz 5.725-5.850 GHz [4] Transmitter Power (EIRP) 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE) Hovering Accuracy Range Vertical: ±0.1 m (with vision positioning) ±0.5 m (with GNSS positioning) Horizontal: ±0.3 m (with vision positioning) ±0.5 m (with high-precision positioning system) |
| Sensing System | Forward Precision Measurement Range: 0.39-25 m Effective Sensing Speed: Flight speed <10.5 m/s FOV: Horizontal 106°, Vertical 90° Backward Precision Measurement Range: 0.36-23.4 m Effective Sensing Speed: Flight speed <8 m/s FOV: Horizontal 58°, Vertical 73° Downward Precision Measurement Range: 0.15-9 m Precise Hovering Range: 0.5-12 m Vision Sensor Hovering Range: 0.5-30 m Effective Sensing Speed: Flight speed <3 m/s FOV: Forward/Backward 104.8°, Left/Right 87.6° Auxiliary Bottom Light N/A Operating Environment Diffuse reflective surface with a clear pattern and reflectivity >20% (such as cement pavement) Adequate lighting (lux >15, e.g. , normal exposure environment with indoor fluorescent lamp) |
| Gimbal | Mechanical Range Tilt: -135° to 80° Roll: -135° to 45° Pan: -30° to 30° Controllable Range Tilt: -90° to 60° Roll: -90° or 0° Stabilization 3-axis mechanical gimbal (tilt, roll, and pan) Max Control Speed (tilt) 100°/s Angular Vibration Range ±0.01° |
| Camera | Sensor 1/1.3-inch CMOS Effective Pixels: 48 MP Lens FOV: 82.1° Format Equivalent: 24 mm Aperture: f/1.7 Focus Range: 1 m to ∞ ISO Range Video: 100-6400 (Auto), 100-6400 (Manual) Photo: 100-6400 (Auto), 100-6400 (Manual) Shutter Speed Electronic Shutter: 2-1/8000 s Max Image Size 8064 × 6048 Still Photography Modes Single Shot: 12 MP 48 MP: 48 MP Burst Shooting: 12 MP, 3/5/7 frames Timed: 12 MP，2/3/5/7/10/15/20/30/60 s Automatic Exposure Bracketing (AEB): 12 MP, 3/5 frames at 2/3 EV step Panorama: Sphere, 180°, Wide Angle, Vertical HDR: The Single Shot mode supports outputting HDR images. Photo Format JPEG/DNG (RAW) Video Resolution 4K: 3840×2160@24/25/30/48/50/60fps 2.7K: 2720×1530@24/25/30/48/50/60fps FHD: 1920×1080@24/25/30/48/50/60fps Slow Motion: 1920×1080@120fps HDR Mode Photo: HDR supported in Single Shot mode Video: HDR supported when shooting at 24/25/30fps Video Format MP4/MOV (H.264/H.265) Max Video Bitrate 150 Mbps Zoom Range 4K: 2x 2.7K: 3x FHD: 4x QuickShot Modes Dronie, Helix, Rocket, Circle, Boomerang, and Asteroid Color Profiles Normal D-Cinelike Supported File System FAT32 (≤32 GB) exFAT (>32 GB) |
| Video Transmission System | Video Transmission System DJI O3 Live View Quality 1080p/30fps Operation Frequency 2.400-2.4835 GHz 5.725-5.850 GHz [4] Transmitter Power (EIRP) 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE) Communication Bandwidth 1.4MHz/3MHz/10MHz/20MHz/40MHz Latency (depending on environmental conditions and mobile device) Aircraft + Remote Controller: Approx. 120 ms Max Video Bitrate Aircraft + Remote Controller: 18 Mbps Max Download Bitrate [5] DJI O3: RC-N1 Remote Controller and DJI RC: 5.5 MB/s Wi-Fi 5: Max 25 MB/s Max Transmission Distance (free of interference) FCC: 12 km CE: 8 km SRRC: 8 km MIC: 8 km Max Transmission Distance (with interference) Strong Interference: urban landscape, approx. 1.5-3 km Medium Interference: suburban landscape, approx. 3-7 km Low Interference: suburb/seaside, approx. 7-12 km Antennas 4 antennas, 1T2R Audio Transmission N/A |
| Wi-Fi | Protocol 802.11 a/b/g/n/ac Transmitter Power (EIRP) 2.400-2.4835 GHz: ＜19 dBm (FCC/CE/SRRC/MIC) 5.725-5.850 GHz: ＜20 dBm (FCC/SRRC), ＜14 dBm (CE) |
| Bluetooth | Protocol Bluetooth 5.2 Transmitter Power (EIRP) 2.400-2.4835 GHz: ＜8 dBm |
| Intelligent Flight Battery | Capacity 2453 mAh Weight Approx. 80.5 g Voltage 7.38 V Charging Voltage Limit 8.5 V Battery Type Li-ion Energy 18.1 Wh Charging Time 64 mins (with the DJI 30W USB-C Charger and the battery mounted to the aircraft) 56 mins (with the DJI 30W USB-C Charger and the battery inserted into the DJI Mini 3 Pro Two-Way Charging Hub) Charging Temperature Range 5° to 40° C (41° to 104° F) Recommended Charger DJI 30W USB-C Charger or other USB Power Delivery chargers (30 W)* * When you charge the battery mounted to the aircraft or inserted into the DJI Mini 3 Pro Two-Way Charging Hub, the maximum charging power supported is 30 W. |
| Intelligent Flight Battery Plus | Capacity 3850 mAh Weight Approx. 121 g Voltage 7.38 V Charging Voltage Limit 8.5 V Battery Type Li-ion Energy 28.4 Wh Charging Time 101 mins (with the DJI 30W USB-C Charger and the battery mounted to the aircraft) 78 mins (with the DJI 30W USB-C Charger and the battery inserted into the DJI Mini 3 Pro Two-Way Charging Hub) Charging Temperature Range 5° to 40° C (41° to 104° F) Recommended Charger DJI 30W USB-C Charger or other USB Power Delivery chargers (30 W)* * When you charge the battery mounted to the aircraft or inserted into the DJI Mini 3 Pro Two-Way Charging Hub, the maximum charging power supported is 30 W. |
| Memory Card | Supported Memory Cards UHS-I Speed Class 3 or above is required. A list of recommended microSD cards can be found below. Recommended microSD Cards SanDisk Extreme 64GB V30 A1 microSDXC SanDisk Extreme 128GB V30 A2 microSDXC SanDisk Extreme 256GB V30 A2 microSDXC SanDisk Extreme 512GB V30 A2 microSDXC SanDisk Extreme Pro 64GB V30 A2 microSDXC SanDisk Extreme Pro 256GB V30 A2 microSDXC SanDisk Extreme Pro 400GB V30 A2 microSDXC SanDisk High Endurance 64GB V30 microSDXC SanDisk High Endurance 256GB V30 microSDXC SanDisk Max Endurance 32GB V30 microSDHC SanDisk Max Endurance 128GB V30 microSDXC SanDisk Max Endurance 256GB V30 microSDXC Kingston Canvas Go!Plus 64GB V30 A2 microSDXC Kingston Canvas Go!Plus 128GB V30 A2 microSDXC Kingston Canvas Go!Plus 256GB V30 A2 microSDXC Lexar High Endurance 64GB V30 microSDXC Lexar High Endurance 128GB V30 microSDXC Lexar 667x 64GB V30 A1 microSDXC Lexar 633x 256GB V30 A1 microSDXC Lexar 1066x 64GB V30 A2 microSDXC Lexar 1066x 128GB V30 A2 microSDXC Lexar 1066x 256GB V30 A2 microSDXC |
| DJI RC-N1 Remote Controller | Transmitter Power (EIRP) 2.400-2.4835 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.725-5.850 GHz: <26 dBm (FCC), <23 dBm (SRRC), <14 dBm (CE) Max Supported Mobile Device Size Length: 180 mm, Width: 86 mm, Height: 10 mm Supported Port Types Lightning, Micro-USB (Type-B), USB-C Video Transmission System DJI O3 Max Battery Time 6 hrs (without charging any mobile device) 4 hrs (when charging a mobile device) Operating Temperature -10° to 40° C (14° to 104° F) |
| DJI RC | Model RM330 Video Transmission System DJI O3 Transmitter Power (EIRP) 2.400-2.4835 GHz: <26 dBm (FCC); <20 dBm (CE/SRRC/MIC) 5.725-5.850 GHz: <26 dBm (FCC), <23 dBm (SRRC), <14 dBm (CE) Storage Capacity DJI RC’s storage capacity can be increased by using a microSD card. Users can store images and videos on the card and export them to a computer or other devices. Video Output Port N/A Max Battery Life Approx. 4 hours Operating Temperature -10° to 40° C (14° to 104° F) Supported SD Cards UHS-I Speed Class 3 or above is required. A list of recommended microSD cards can be found below. Recommended microSD Cards SanDisk Extreme 64GB V30 A1 microSDXC SanDisk Extreme 128GB V30 A2 microSDXC SanDisk Extreme 256GB V30 A2 microSDXC SanDisk Extreme 512GB V30 A2 microSDXC SanDisk Extreme Pro 64GB V30 A2 microSDXC SanDisk Extreme Pro 256GB V30 A2 microSDXC SanDisk Extreme Pro 400GB V30 A2 microSDXC SanDisk High Endurance 64GB V30 microSDXC SanDisk High Endurance 256GB V30 microSDXC Kingston Canvas Go!Plus 64GB V30 A2 microSDXC Kingston Canvas Go!Plus 256GB V30 A2 microSDXC Lexar High Endurance 64GB V30 microSDXC Lexar High Endurance 128GB V30 microSDXC Lexar 633x 256GB V30 A1 microSDXC Lexar 1066x 64GB V30 A2 microSDXC Samsung EVO Plus 512GB microSDXC Wi-Fi Protocol 802.11 a/b/g/n Wi-Fi Transmitter Power (EIRP) 2.400-2.4835 GHz: <23 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.150-5.250 GHz: <23 dBm (FCC/CE/SRRC/MIC) 5.725-5.850 GHz: <23 dBm (FCC/SRRC), <14 dBm (CE) Bluetooth Protocol Bluetooth 4.2 Bluetooth Transmitter Power (EIRP) 2.400-2.4835 GHz: <10 dBm |
| Charging Hub | Compatible DJI Charger DJI 30W USB-C Charger or other USB Power Delivery chargers (30 W) * When you charge a battery mounted to the aircraft or inserted into the DJI Mini 3 Pro Two-Way Charging Hub, the maximum charging power supported is 30 W. Compatible DJI Batteries DJI Mini 3 Pro Intelligent Flight Battery, DJI Mini 3 Pro Intelligent Flight Battery Plus [7] Input 5 V, 3 A 9 V, 3 A 12 V, 3 A Output (USB) Max Voltage: 5 V, Max Current: 2 A Charging Type Three batteries being charged in sequence |
| App | Mobile Device App DJI Fly Required Operating System iOS v11.0 or later Android v6.0 or later |
| Other | Footnotes 1. Standard aircraft weight (including DJI Mini 3 Pro Intelligent Flight Battery, propellers, and a microSD card). The actual product weight may vary due to differences in batch materials and external factors. Training or examination is not required for flying this product in most countries and regions. Always check local laws and regulations before use. Data was measured with the latest firmware. Firmware updates can enhance product performance, so updating to the latest firmware is highly recommended. With the DJI Mini 3 Pro Intelligent Flight Battery Plus, the aircraft will weigh more than 249 g (about 290 g). Always check and strictly abide by local laws and regulations before flying. 2. The max flight speed is subject to local restrictions that may change. Please abide by local laws and regulations when flying. 3. Increase in aircraft weight can affect flight propulsion. When the aircraft is using the Intelligent Flight Battery Plus, do not mount additional payloads like a propeller guard or third-party accessories to avoid a lack of propulsion. 4. Due to local policy and regulation restrictions, the 5.8 GHz frequency band is currently banned in certain countries, including but not limited to Japan, Russia, Israel, Ukraine, and Kazakhstan. Please use the 2.4 GHz frequency band when operating in these locations. Always check local rules and regulations before use, as they may change over time. 5. Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz. With footage saved on an SD card or the internal storage. Download speeds may vary depending on actual conditions. 6. Data is tested under FCC standards in unobstructed environments of typical interference. Only to serve as a reference and provides no guarantee as to the actual flight distance. Max one-way communication distance of DJI Mini 3 Pro in countries/regions of different standards: FCC: United States, Australia, Canada, Hong Kong, Taiwan, Chile, Colombia, Puerto Rico, and other regions. Max transmission range: 12 km SRRC: Mainland China. Max transmission range: 8 km CE: UK, Russia, France, Germany, Portugal, Spain, Switzerland, Macau, New Zealand, UAE, and other regions. Max transmission range: 8 km MIC: Japan. Max transmission distance: 8 km 7. Sold separately and only in selected countries and regions. |
