Born to Fly
Highlights
- Immersive Flight Experience
- Intuitive Motion Controller
- 4K Stabilized Video
- Palm-Sized and Agile
- Built-in Propeller Guard
- HD Low-Latency Transmission
Specs
| Camera | Sensor 1/1.7-inch CMOS Effective Pixels: 48 MP Lens FOV: 155° Equivalent Focal Length: 12.7 mm Focal Length: 2.34 mm Aperture: f/2.8 Focus Mode: FF Focus Range: 0.6 m to ∞ ISO Range 100-6400 (Auto) 100-25600 (Manual) Shutter Speed Video: 1/8000-1/50 s Photo: 1/8000-1/50 s Still Photography Mode Single Shot Max Image Size 4000×3000 Photo Format JPEG Video Resolution With DJI Goggles 2: 4K@30/50/60fps 2.7K@30/50/60/100/120fps 1080p@30/50/60/100/120fps With DJI FPV Goggles V2: 4K@30/50/60fps 2.7K@30/50/60/100/120fps 1080p@30/50/60/100/120fps Video Format MP4 Max Video Bitrate 150 Mbps Color Mode Standard D-Cinelike EIS Supports RockSteady and HorizonSteady Can be disabled Distortion Correction Supports Normal Mode, Wide Mode, and Ultra Wide Mode Supported File System exFAT |
| Gimbal | Mechanical Range Tilt: -95° to 75° Controllable Range Tilt: -80° to +65° Stabilization Single-Axis (tilt) Max Control Speed 60°/s Angular Vibration Range ±0.01° Electronic Roll Axis Real-time screen correction is unavailable during recording, but can be applied to the footage recorded on the drone. |
| Aircraft | Model QF2W4K Takeoff Weight Approx. 410 g Dimensions (L×W×H) 180×180×80 mm Diagonal Distance 120 mm Max Ascent Speed 6 m/s (Normal Mode, Sport Mode) Max Descent Speed 6 m/s (Normal Mode, Sport Mode) Max Speed 8 m/s (Normal Mode) 14 m/s (Sport Mode) 27 m/s (Manual Mode) Maximum Takeoff Altitude 5000 m Max Hover Time Approx. 18 mins Max Flight Distance 11.6 km Max Wind Speed Resistance 10.7 m/s (Level 5) Operating Temperature Range -10° to 40° C (14° to 104° F) Transmission Power (EIRP) FCC: < 33 dBm CE: < 14 dBm SRRC: < 30 dBm Antennas Dual Antennas, 2T2R GNSS GPS + Galileo + BeiDou Hovering Accuracy Range Vertical: ±0.1 m (with Vision Positioning) ±0.5 m (with GNSS Positioning) Horizontal: ±0.3 m (with Vision Positioning) ±1.5 m (with GNSS Positioning) Supported SD Cards microSD (up to 256 GB) Recommended microSD Cards SanDisk Extreme U3 V30 A1 32GB microSDXC SanDisk Extreme Pro U3 V30 A1 32GB microSDXC Kingston Canvas Go!Plus U3 V30 A2 64GB microSDXC Kingston Canvas React Plus U3 V90 A1 64GB microSDXC Kingston Canvas React Plus U3 V90 A1 128GB microSDXC Kingston Canvas React Plus U3 V90 A1 256GB microSDXC Samsung PRO Plus U3 V30 A2 256GB microSDXC Internal Storage 20 GB |
| Sensing System | Downward (Binocular Vision and ToF) ToF Effective Measurement Height: 10 m Precise Hovering Range: 0.5-10 m Vision Sensor Hovering Range: 0.5-20 m Operating Environment Diffuse reflective surfaces with a clear pattern > 20% (such as walls, trees, or people) Adequate lighting (lux > 15, normal indoor lighting conditions) |
| Intelligent Flight Battery | Battery Capacity 2420 mAh Voltage 14.76 V Charging Voltage Limit 17 V Type Li-ion Chemical System LiNiMnCoO2 Energy 35.71 Wh@0.5C Discharge Rate Typical: 7C Weight Approx. 162 g Charging Temperature Range 5° to 40° C (41° to 104° F) |
| Video Transmission | Communication Frequency 2.400-2.4835 GHz (RX only) 5.725-5.850 GHz (RX and TX) Communication Bandwidth Max 40 MHz Live View Quality and Latency With DJI FPV Goggles V2: 810p/120fps Video Transmission Quality: The video transmission latency is lower than 28 ms. 810p/60fps Video Transmission Quality: The video transmission latency is lower than 40 ms. With DJI Goggles 2: 1080p/100fps Video Transmission Quality: The video transmission latency is as low as 30 ms. 1080p/60fps Video Transmission Quality: The video transmission latency is as low as 40 ms. Max Video Transmission Bitrate 50 Mbps Max Video Transmission Range 10 km (FCC), 2 km (CE), 6 km (SRRC) Audio Transmission N/A |
| DJI Goggles 2 | Model RCDS18 Weight Approx. 290 g (headband included) Dimensions (L×W×H) With antennas folded: 167.40×103.90×81.31 mm With antennas unfolded: 196.69×103.90×104.61 mm Screen Size (single screen) 0.49-inch Resolution (single screen) 1920×1080 Refresh Rate Up to 100 Hz Interpupillary Distance Range 56-72 mm Diopter Adjustment Range -8.0 D to +2.0 D FOV (single screen) 51° Communication Frequency 2.400-2.4835 GHz 5.725-5.850 GHz Transmission Power (EIRP) 2.4 GHz: < 30 dBm (FCC), < 20 dBm (CE/SRRC/KC) 5.8 GHz [4]: < 30 dBm (FCC), < 23 dBm (SRRC), < 14 dBm (CE/KC) Wi-Fi Protocol Wi-Fi 802.11b/a/g/n/ac Wi-Fi Communication Frequency 2.400-2.4835 GHz 5.150-5.250 GHz (indoor use only) [8] 5.725-5.850 GHz Wi-Fi Transmission Power (EIRP) 2.4 GHz: < 20 dBm (FCC/CE/SRRC/KC) 5.1 GHz [8]: < 20 dBm (FCC/CE/KC) 5.8 GHz [4]: < 20 dBm (FCC/SRRC/KC), < 14 dBm (CE) Bluetooth Protocol Bluetooth 5.2 Bluetooth Communication Frequency 2.400-2.4835 GHz Bluetooth Transmission Power (EIRP) < 8 dBm Max Video Transmission Bitrate 50 Mbps Video Recording Format MOV Supported Video and Audio Playback Formats MP4 and MOV (video coding formats: H.264 and H.265; audio format: ACC, PCM) Wi-Fi Wireless Streaming Supports DLNA Protocol Operating Temperature Range -10° to 40° C (14° to 104° F) Power Input DJI Goggles 2 Battery Supported SD Cards microSD (up to 256 GB) |
| DJI Goggles 2 Battery | Capacity 1800 mAh Voltage 7-9 V (1.5 A) Type Li-ion Chemical System LiNiMnCoO2 Energy 18 Wh Charging Temperature Range 0° to 45° C (32° to 113° F) Max Charging Power 12.6 W (5 V/2 A, 9 V/1.4 A) Weight Approx. 122 g Dimensions (L×W×H) 73.04×40.96×26 mm Operating Time Approx. 2 hours |
| DJI FPV Goggles V2 | Model FGDB28 Weight Approx. 420 g (headband and antennas included) Supported Video and Audio Playback Formats MP4, MOV, MKV (video coding format: H.264; audio formats: AAC-LC, AAC-HE, AC-3, MP3) Operating Temperature Range 0° to 40° C (32° to 104° F) Video Recording Format MOV (video coding format: H.264) FOV 30° to 54°, adjustable Image Size: 50% to 100% Communication Frequency 2.400-2.4835 GHz 5.725-5.850 GHz Max Video Transmission Bitrate [6] 50 Mbps Dimensions (L×W×H) Without antennas: 184×122×110 mm With antennas: 202×126×110 mm Transmission Power (EIRP) 2.400-2.4835 GHz FCC: ≤ 28.5 dBm CE: ≤ 20 dBm SRRC: ≤ 20 dBm 5.725-5.850 GHz [4] FCC: ≤ 31.5 dBm CE: ≤ 14 dBm SRRC: ≤ 19 dBm Screen Size (single screen) 2-inch Power Input Dedicated DJI Goggles batteries Supported SD Cards microSD (up to 256 GB) Communication Bandwidth Max 40 MHz Interpupillary Distance Range 58-70 mm Refresh Rate 144 Hz Screen Resolution 1440×810 |
| DJI FPV Goggles V2 Battery | Weight Approx. 119 g Dimensions (L×W×H) 73.04×40.96×26 mm Capacity 1800 mAh Voltage Max 9 V Chemical System LiNiMnCoO2 Type Li-Po 2S Energy 18 Wh Charging Temperature Range 0° to 45° C (32° to 113° F) Max Charging Power 10 W Operating Time Approx. 110 mins |
| DJI Motion Controller | Model FC7BMC Weight Approx. 167 g Communication Frequency 2.400-2.4835 GHz 5.725-5.850 GHz Transmission Power (EIRP) 2.4 GHz: ≤ 28.5 dBm (FCC), ≤ 20 dBm (CE/SRRC) 5.8 GHz [4]: ≤ 31.5 dBm (FCC), ≤ 19 dBm (SRRC), ≤ 14 dBm (CE) Operating Temperature Range -10° to 40° C (14° to 104° F) Operating Time Approx. 5 hours |
| DJI FPV Remote Controller 2 | Model FC7BGC Weight Approx. 346 g Communication Frequency 2.400-2.4835 GHz 5.725-5.850 GHz Transmission Power (EIRP) 2.4 GHz: ≤ 28.5 dBm (FCC), ≤ 20 dBm (CE/SRRC) 5.8 GHz [4]: ≤ 31.5 dBm (FCC), ≤ 19 dBm (SRRC), ≤ 14 dBm (CE) Dimensions (L×W×H) 190×140×51 mm Operating Time Approx. 9 hours Operating Temperature Range -10° to 40° C (14° to 104° F) Charging Time 2.5 hours |
| Other | Footnotes 1. The max flight speed is subject to dynamic local restrictions. Please abide by local laws and regulations when flying. 2. Tested when hovering in an environment without wind or interference. 3. DJI Avata only supports downward obstacle sensing when used with DJI FPV Remote Controller 2, or DJI Motion Controller in N Mode and S Mode. 4. The 5.8 GHz frequency band is currently banned in certain countries or regions. For details, please refer to local laws and regulations. 5. Tested in an outdoor open environment without interference. The video transmission latency data varies with different models. 6. Tested in an outdoor open environment without interference. The video transmission bitrate varies with operating environments. 7. FCC compliant and tested in an outdoor open environment without interference. Data is tested under different standards in an outdoor open environment without interference. Only to serve as a reference for the max one-way communication distance without considering RTH. Please pay attention to the RTH prompts during actual flight. Max one-way communication distance of DJI Avata in countries/regions of different standards: FCC: United States, Australia, Canada, Hong Kong, Taiwan, Chile, Colombia, Puerto Rico, and other regions. SRRC: Mainland China. CE: UK, France, Germany, Portugal, Spain, Switzerland, Macau, New Zealand, UAE, and other regions. 8. The 5.1 GHz frequency band is currently banned in Thailand. For details, please refer to local laws and regulations. |
