Fast Forward to Victory
Highlights
- ICE 8.0 Magic Cooling System
- 65W GaN Charger & 4500mAh Dual-Cell Large Battery
- Dual Independent IC Game Shoulder Buttons – 500Hz Touch Refresh Rate
- New Snapdragon 8 – Full Blood Version LPDDR5+UFS3.1
- Arc Performance Enhancements – Magic Write + RAM Boost + Magic CPU
- 165Hz High-Refresh Screen – 720Hz Multi-touch Sampling Data
- RedMagic OS 5.0
Specs
| Basic Parameters | Height: 170.57mm Width: 78.33mm Depth: 9.5mm Weight: 215g Material: Metal Middle Frame + Glass Back Cover Color: Obsidian 12+128 / Pulsar 16+256 / Supernova 18+256 |
| Display | Size: 6.8 inches FHD+ Refresh Rate: up to 165Hz Touch Sampling Rate: up to 720Hz multi-touch Resolution: 2400×1080 pixels Aspect Ratio: 20:9 Type: AMOLED Brightness: 700 nits max brightness (standard) 4,096 levels of smart brightness control SGS Certification low blue light for eye comfort Material: 2.5D Corning® Gorilla® Glass Color Gamut: 100% DCI-P Contrast Ratio: 1000,000:1 (typical) |
| Cooling System | Turbo Fan Area of Air-duct: 4000mm² Air Channel with 2 air intakes Air Volume: 0.21CFM，0.295 (MIN. 0.232) CFM Type: Centrifugal fan Number of fan blades: 59 Thickness of fan blades: 0.1mm Tested life: 30,000 hours Speed: 20,000 RPM Material: Aircraft grade aluminum alloy Weight: 1g The other cooling components Vapor Chamber High Thermal Conductivity Copper Foil Thermal gel Cooling Graphite Thermal Pad Aviation Grade Aluminum Heat Sink |
| Hardware | Qualcomm Snapdragon® 8 Gen 1 CPU Cores: Kryo™ CPU Clock Speed: up to 3.0 GHz GPU: Adreno™ |
| Capacity* | RAM: 12/16/18 GB LPDDR5 ROM: 128/256 GB UFS3.1 *Actual memory space is less and varies due to many factors |
| Connectivity | Network SIM: dual nano-SIM SA+NSA: compatible with both standalone and non-standalone modes 2G: GSM 2/3/5/8 3G: WCDMA B1/B2/B4/B5/B6/B8/B19 CDMA/EVDO BC0/BC1 4G: TD-LTE B34/B38/B39/B40/B41 FDD-LTE B1/B2/B3/B4/B5/B7/B8/B12/B17/B18 /B19/B20/B26/B28A/B66 5G NR: NSA: n41/n78/n77/n38 SA: n41/n78/n1/n77（3600M-4100M）/n28A/n3/n7/n8/n20/n5 WiFi: WiFi6 802.11ax ready 2×2 802.11ac MU-MIMO with DBS support Bluetooth: Bluetooth 5.2 Positioning: GPS, GLONASS NFC: Yes HDMI: Yes |
| Cameras | Rear Camera Sensors: S5KGW3+HI846+OV02A10 Resolution: 64MP+8MP+2MP Wide Angle: 80°+120°+78° Aperture: F1.75+F2.2+F2.4 Slow Motion: 120fps, 240fps, 480fps, 960fps Time-Lapse: Yes Front Camera Megapixels: 8MP Pixel Size: 1.12μm Aperture: 2.0 Video shooting: the rear cameras supports 8K resolution at 30fps, 4K at 60fps/30fps, 1080P at 60fps/30fps, 720P at 30fps; the front camera supports 1080P/720P at 30fps |
| Sensors | Fingerprint, G-sensor, Electronic Compass, Gyroscope, Proximity, Ambient Light Sensor, Sensor hub |
| Operating System | RedMagic OS 5.0 based on Android 12.0 |
| Ports | USB Type-C 3.0, USB On-The-Go; accessory connector |
| Battery & Quick Charging | Quick Charging: 65W GaN quick charging |
| Audio Supported Formats | Playback: WAV, AAC, MP3, AMR, FLAC, OGG, APE Recording: WAV, AAC, AMR |
| Video Supported Formats | Playback: 3GP, ASF, AVI, FLV, M2TS, MKV, MOV, MP4, MPG, MTS, TS, WEBM, WMV, MPEG, M4V Recording: MP4 |
| Image Supported Formats | Playback: JPEG, PNG, GIF, BMP, WBMP, HEIC Output: JPEG |
| Special Functions | Shoulder Trigger Buttons: 500Hz touch sampling rate touchpads Game Space Switch: Toggles special game mode on or off. RGB Light: fully customizable lighting effects |
