Highlights
- Fast 3202Mbps Wi-Fi 6*
- Mesh networking support
- OFDMA – Multi-device transmission with less congestion
- Supports 4×4 MU-MIMO
Specs
| Dimension (L×W×H) | 284mm × 186mm × 186mm |
| Product color | Black |
| Hardware configuration | Processor MediaTek Filogic800 Dual-core A53 1.35GHz CPU Memory 256MB 2.4GHz Wi-Fi 4×4 (supports up to IEEE 802.11n protocol, the theoretical maximum rate is 800Mbps) 5GHz Wi-Fi 4×4 (supports up to IEEE 802.11ax protocol, the theoretical maximum rate is 2402Mbps) Antennas External omnidirectional antennas Total ports 10/100/1000Mbps adaptive WAN port (Auto MDI/MDIX) ×1 10/100/1000Mbps adaptive LAN ports (Auto MDI/MDIX) ×3 LED indicator light 2 lights, incl. System indicator × 1, Internet indicator × 1 System reset button×1 Mesh networking button×1 Power input port×1 Protocol standards IEEE 802.11a/b/g/n/ac/ax，IEEE 802.3/3u/3ab |
| Wireless Specification | Dual-band 2.4GHz, 5GHz Modulation 11b：DSSS：DBPSK(1Mbps),DQPSK(2Mbps),CCK(5.5/11Mbps)11a/g：OFDM:BPSK(6/9Mbps),QPSK(12/18Mbps),16QAM(24/36Mbps), 64QAM(48/54Mbps)11n：MIMO-OFDM:BPSK,QPSK,16QAM,64QAM.256QAM.11ac：MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM.11ax：MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM,1024QAM. |
| Software specifications | Operating system MiWiFi ROM, a smart router operating system based on OpenWRT Wi-Fi Encryption WPA-PSK/WPA2-PSK/WPA3-SAE encryption Management applications Supports Web, Android, iOS |
| Working Environment | Working environment temperature 0-40℃ Operating humidity 10%-90%RH (non-condensing) Storage temperature -40-70℃ Storage humidity 5%-90%RH (non-condensing) |
